BodenWarme Electric Undertile Heating Mat 150w with White dSTAT Thermostat

Code:

MAT150WHITEdSTAT

Brand:

Transform your home with the BodenWärme 150W Electric Undertile Heating Mat and sleek white dSTAT thermostat, an energy-efficient, hassle-free way to bring luxury warmth to porcelain, ceramic, and natural stone floors. Say goodbye to cold spots and uneven heating as this syste... Read More

View full product details

Ask a question about this product

Coverage

from

£61.99 Incl. VAT

£51.66 Ex. VAT

Earn 61 points

Delivery from: 1-2 Working Days

Shipping costs displayed in basket.

For delivery Wednesday, Apr 23rd - order in:

4days 16hrs 36mins 8secs

For delivery Wednesday, Apr 23rd - order in:

4days 16hrs 36mins 8secs

View Transport Policy

View full product details

Ask a question about this product

Create a wishlist

Description

Designed for effortless installation, the rapid-fit sticky mesh allows for seamless setup, while the ultra-thin 3.6mm dual-core wire minimises floor height. The durable Fluoropolymer insulation guarantees long-lasting performance. The modern white dSTAT thermostat boasts adaptive learning, 7-day programming, and a Key Lock function, giving you total control at your fingertips. For faster heating and reduced energy waste, pair with 6mm or 10mm insulation boards.

Features & Benefits: BodenWarme Electric Undertile Heating Mat 150w with White dSTAT Thermostat

Lifetime manufacturer-backed warranty
Rapid fit sticky mesh for quick installation
Robust 3.6mm wire keeps the increase in floor height to a minimum

How do I calculate the correct size of BodenWärme heating kit?

First measure the total floor area by multiplying the width by the length. Then subtract fixed furniture with a clearance of less than 50mm above the floor to prevent hot spots. With the total area minus deductions, deduct an additional 10% as this will allow for the spacing between mats and around the perimeter of the room.

Kit Contents

BodenWärme 150w/m² underfloor heating mat with rapid fit sticky mesh
dSTAT electric underfloor thermostat in white
Floor temperature sensor with 3m cable and flexible conduit
Installation manual
25mm fixing tape

Standards & Certification

Fully CE Certified
RoHS Compliant (for guaranteed safety)

Please note:

Mats cannot be cut or trimmed; once altered, they are non-returnable.
A single thermostat controls up to 20m² of 150W/m² BodenWärme heating mats. Larger areas require separate zones with multiple thermostats.
All mains electrical connections must be done by a certified electrician per Part P regulations. The system must be protected by a 30mA RCD, located in the consumer unit or a dedicated fused spur.
Ensure the total current does not exceed the circuit's capacity. A standard 13A domestic ring circuit can power the system via a single 13A fused spur.

Specification

Details

Coverage1m2
1.5m2
2m2
2.5m2
3m2
3.5m2
4m2
4.5m2
5m2
6m2
7m2
8m2
9m2
10m2
11m2
12m2
13m2
14m2
15m2
16m2
17m2
18m2
19m2
20m2Wattage Output150w / m2Power SupplyAC230V +/-10% 50/60HzCertificationROHS
CEElement StructureDual Core Wire

Cable Thickness3.6mmCold Tail Length3mCable Spacing80mmEarth Type100% Coverage Earth ShieldConductor InsulationFluoropolymer

Heat Mat WarrantyLifetime WarrantySuitable ForNatural Stone
Ceramic Tiles
Porcelain TilesOuter InsulationPVC
